Triple-R 1250 Elite+
Triple-R 1250 Elite+ Triple-R 1250 Elite+ Triple-R 1250 Elite+ Image of the complete wiring kit including connectors, relays, fuses, switches, and bundled cables prepared for installation.

Triple-R 1250 Elite+

Rating:
100%
Product Code
00R12-G2-PLUS-B
£840.00
Find a Stockist

PAYMENT & DELIVERY
Orders will be shipped within 1 working day (stock permitting). UK customers will be given the option for Standard or Express delivery service. International orders will dispatch via Express Courier Service, on a DAP (Delivered At Place) basis, meaning you will be liable for country specific VAT and import dutiesMore Information.

Representing an evolution in our highest performance LED lighting solutions, the Elite+ range comprises products with enhanced performance, light distribution, and functionality. Improvements are in part made through the placement of supplemental yellow LEDs in each of the lights, which can either combine with the already superior white light high beam function for awe-inspiring night-time visibility at a slightly softer, more relaxing colour temperature. Or the option to operate the yellow LEDs on their own, with that light angled slightly down and to the sides of the road or track making this function ideal in snow, fog, or dust conditions.

The lights are intended to cycle through the different lighting modes via a momentary switch. The lighting modes are: Boost (white only), Combo (white + yellow), Snow/Fog/Dust Mode (yellow only), and E-mark (white only; road-legal at reduced output compliant with UNECE Reg 149). A memory function within the lamp means the previous mode selected will be in effect when your vehicle is restarted for example. Additionally, pressing and holding the momentary switch for 2 seconds will result in the light instantly jumping to the E-mark mode.

The impressive proportions of the Triple-R 1250 are reflected in the lamp’s performance. Through advanced electronic design the light consists of a combination of 24 white LEDs and 20 yellow LEDs. With the light operating in Boost mode the white LEDs produce 12,028 raw lumen. Switching to ‘Combo’ mode the white and yellow LEDs combine to produce 21,388 raw lumen representing incredible lighting performance for a safer, more enjoyable night driving experience. All LEDs operating in combination results in 220W power consumption and 16.9Amps current draw (at 14V). To support operation of the lamp and electrical installation, the lamp features both a high power 2-pin Econoseal, and 3-pin Superseal connector. Additionally, included with each lamp are corresponding vehicle side wiring kits. The Econoseal connection is responsible for the high beam operation of the light, while the Superseal connections relate to the: function select, white and amber position light/backlight selection.

Like all Lazer products, the Elite+ range has been designed, engineered, and is manufactured in-house in the UK to exacting standards, both in terms of performance, reliability, and appearance. With the light’s contemporary design, the styling and finish is impressive especially up-close, but the true wow moments comes when you turn the light on at night! Backed up by our comprehensive 5-year warranty, and Lifetime Lens Guarantee, this is a product you can have confidence will last for years in even the harshest environments.

Combination of highly efficient white (5000k) and PC-yellow LEDs.

Yellow LEDs optimised for use in snow / fog / dust conditions.

Integrated white and amber position light function.

White light ECE approved to Reg 149 (Class B, Driving Light) for on-road use (E-Boost technology), and Reg 148 position/side light function (white only).

Features pre-wired male/female 2-pin Econoseal and 3-pin Superseal connectors.

Supplied with One-Lamp Wiring Kit.

Momentary switch facilitates switching lighting modes.

Memory function recalls preferred lighting mode without needing to re-select each journey.

Includes ‘Centre Mount’ and Side Mounting Kit.

CAE optimised heatsink offers improved thermal dynamics.

Anodised pre-treatment and Automotive grade powder top-coat for ultimate corrosion and chemical protection.

Electronic thermal management system optimises light output to preserve longevity of the LEDs .

‘Unbreakable’ and hardcoated polycarbonate lens

IP68 watertight

5-year warranty

Designed & manufactured in the UK

TRIPLE-R 1250 ELITE+ BOOST MODE LOW OUTPUT / E-MARK MODE FOG/DUST/SNOW MODE COMBO MODE
Voltage Range (DC)10-32V
LED Life50,000 hrs
Weight2.4 kg
HIGH BEAM FUNCTION
Total Luminous Flux12,028 Lm2,045 Lm9,360 Lm21,388 Lm
Total Driver 'FOV' Flux 7,464 Lm1,269 Lm5,273 Lm12,737 Lm
Colour TemperatureWhite LED's (5000K))White LED's (5000K)Yellow LED'sWhite & Yellow LED's
Power Consumption131 Watts19.6 Watts92 Watts243 Watts
Current Draw (14.4V)9.1 Amps1.4 Amps6.4 Amps16.9 Amps
Peak Current Draw12 Amps1.8 Amps8.5 Amps22.8 Amps
Connector2-Pin Econoseal & 3-Pin Superseal connections (+25cm Cable)
CERTIFICATION
IP Rating #IP68
High Beam (E9 approval)ECE R149 - Ref: 20 (in Low Output Mode only)
Postion Light (white)ECE R148
EMC CertificationECE R10
Salt Spray TestISO 9227
Dump Load ProtectionISO 7637-2

- Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's field-of-view, defined as an area +/- 45° left/right, and +/- 10° up/down. For more information click here.

# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at our UK facility is fully submerged under water prior to sending out.


PHOTOMETRIC DATA BOOST MODE LOW OUTPUT / E-MARK MODE FOG/DUST/SNOW MODE COMBO MODE
0.25 lx Line1470 metres616 metres980 metres1649 metres
0.5 lx Line1039 metres436 metres693 metres1166 metres
1 lx Line735 metres308 metres490 metres825 metres
3 lx Line424 metres178 metres283 metres476 metres
Triple-R 1250 Elite Plus photometric diagram
BEAM DISTRIBUTION
Horizontal54 degrees
Vertical15 degrees
Triple-R 1250 Elite Plus distribution
Triple-R 1250 Elite Plus Beam Photo
DIMENSIONS
Width590mm
Depth105mm
Height73mm
Triple-R 1250 Elite Plus dimensions diagram
  • x1 Triple-R 1250 Elite+ LED Lamp
  • x2 Centre Mount (1114k)
  • x2 Wiring Kits (Econoseal & Superseal connections)
  • x1 Installation Instructions
Downloads

CLICK BELOW TO DOWNLOAD (OPENS PDF IN NEW WINDOW)


Discover more lighting POV footage, step-by-step installations, and other helpful tips on our YouTube channel.

@LAZERLAMPS
