The latest in the Lazer Lamps’ range of LED work lights, the Utility-25 MAXX is a hugely versatile, medium-duty work light. The lamp incorporates higher output 11W LEDs to deliver seriously impressive lighting performance, especially considering the lamps’ comparatively small proportions, something made possible through continued improvements in LED electronics design, coupled with the lamps’ robust physical design. Sharing product DNA with the larger Utility-45 and Utility-80 heavy duty work lights, the lamp is built tough and engineered to deliver constant, reliable light output perfectly tuned to a broad range of applications and vehicle types.



Measuring 80mm x 80mm, and capable of operating between 9-32V, the Utility-25 MAXX utilises highly efficient 11W LEDs from a world-leader in LED design and manufacture. Like all Lazer products, the colour temperature of the LEDs is carefully selected at 5000 kelvin to maximise sharpness and definition of the area ahead, without causing fatigue or strain which can come from using LEDs with a higher colour range. The vacuum-metallised optics harness the 4,560 raw lumens delivering 78 degree spread (to 10% of peak intensity). The impressive lighting performance is maintained through the high thermal conductivity of the ‘Matrix’ cooling system which allows the lamp to be run at a higher drive current without compromising the longevity of the LEDs themselves.



Designed and manufactured in the UK, the Utility-25 MAXX is a product built to last, and to withstand harsh environments, backed up by a comprehensive 5yr warranty*. The polycarbonate lens with hardcoat, is bonded in place to guarantee water-tightness (IP69K), while the lamps have undergone extensive testing to comply with EU regulations in relation to vibration, shock, and corrosion resistance. Advanced electronic design ensures full EMC protection to CISPR-25 (Class 4) standards.



Supplied with male/female Deutsch connectors (part no. DT04-2S/DT04-2P), and ADR approved thanks to additional cable protection, the Utility-25 MAXX also comes supplied with a satin black-painted stainless-steel mounting system, which allows flexibility in mounting the light in many different orientations.



* 5 Year Warranty applies for Automotive and Commercial Fleet use, all other applications, a 2 Year Warranty period applies.

PAYMENT & DELIVERY INFORMATION

Please note all transactions are completed in GBP:

Paypal / Visa / Mastercard / AmexSecure Payment

DELIVERY – UK CUSTOMERS

Van icon

Goods will be shipped via courier within 1 working day of your order being placed (stock permitting). At the checkout stage you will be given Standard (£10 ex VAT) or Express (£20 ex VAT) shipping options. For more information visit our Delivery Information page.

DELIVERY – EUROPE & REST OF THE WORLD

Global delivery symbol

Goods will be shipped via Express courier service within 2 working days of your order being placed (stock permitting). Goods are typically sent DAP (Delivered At Place) meaning you will be liable for country specific VAT, import duties, and courier disbursement fees. For more information please visit our Payment Terms page. To avoid unnecessary charges, we would encourage customers to consider buying from a local dealer. For a full list of countries we ship to, plus service levels and prices, please visit our Delivery Information page.

Utility-25 MAXX

ECE (Reg 10) approved Work Light

CAE optimised 'Matrix' cooling system

Advanced optical design delivers superior lighting performance

Electronic thermal management

Certified IP67/IP69K watertight

ADR Approved

Automotive grade corrosion resistance (ISO 9927 / BS EN 60068)

5,000 kelvin light temperature for maximum definition

EMC protected - CISPR 25: 2008 (Class 4) certified

Vibration Certified (BS EN 60068) : 10Hz - 2000Hz, 1 oct/min, 10gn

Over voltage protected

Reverse polarity protected

Male and female 2-pin Deutsch connectors included

5 Year warranty*

Made in Britain

Technical Specifications
Voltage Range (DC) 10-32V
LED Life 50,000 hours
Colour Temperature 5,000 Kelvin
Weight 360 gr
HIGH BEAM FUNCTION
Total Luminous Flux 4560 Lm
Colour Temperature 5000K
Number of High Output LEDs 4
Power Consumption 45 Watts
Current Draw (at 14.4V) 3.1 Amps
CERTIFICATION
Work Lamp  ECE R10
IP Rating IP69K
Salt Spray Test ISO 9227 (1000H)
EMC Protection CISPR-25 (Class 4)
OPERATING CONDITIONS
Shock TBC
Vibration (BS EN 60068-2-64) 10Hz > 1000Hz, 0.14>20 (m/s²)²/Hz
Operating Temperature -40deg C ... +90degC
DIMENSIONS
Width 80 mm
Depth 56 mm
Height 80 mm
PHOTOMETRIC DATA
1Lx Line @ 62m
5Lx Line @ 37m
20Lx Line @ 21m
50Lx Line @  14m*

* - 50Lx represents HSE guidelines for effective illumination when working outdoors at night.
