T16 Evolution

Product Code
0016-EVO-B
£632.00

Find a
Stockist

Delivering 16,544 lumens, the T16 Evolution is re-engineered and re-designed for 2017/8 to provide more light, better range, and increased spread of light, with the peace of mind that the build quality has been even further enhanced to ensure trouble-free operation for well beyond the standard 5year warranty. At 684mm, the lamp is ideal for customers looking for a low profile off-road lighting solution that still manages to pack real punch, or for road customers looking for a full-size grille install that works off an independent switch.

Upgraded high-density 11W LEDs are carefully selected for their high ‘bin’ rating, are the driving force behind the lamps enviable performance – 1 lux is achieved at 555m. Advanced electronic design, combined with sophisticated thermal management systems, and ultra-reflective vacuum-metallised reflectors, harness the light output into a ‘Drive’ beam pattern optimised for lower speed applications where the priority is for good all-round visibility, albeit still with enviable distance illumination. The colour temperature of the LEDs at 5000 kelvin has also been specifically selected to maximise sharpness and definition, while proven to reduce eye-strain associated with some higher (blue-white) colour temperatures.

Performance aside, the T16 Evolution is built to last. With a 5 year warranty as standard, and a lifetime guarantee on the ‘unbreakable’ polycarbonate lens, which is coated with a hardcoat lacquer to protect against any scratches, the lamp is capable of withstanding the harshest environments. An IP69K rating certifies the lamp will not be subjected to moisture or dust ingress, with additional counter-measures to ensure the unit remains fully contained even in the most extreme of temperatures and humidity. The full aluminium housing gives the lamp its strength and rigidity, while an e-coat pre-treatment provides automotive quality corrosion resistance. Dynamic drive modulation optimises light output considering the thermal conditions of the lamp (preserving the longevity of the LEDs).

With a seamless, low profile design, the new T Evolution range is now not only easier to install, but is more resistant to dirt, snow and ice accumulations, and the contemporary styling is guaranteed to complement and enhance the appearance of modern vehicles.

What's included:
- x1 T16 Evolution LED Spotlight
- x2 Centre Mount (1114k)
- x1 Side Bracket Kit (1118k)
- x1 Single-Lamp Wiring Kit with Switch (1L-HP-300)
- x1 Wiring and Installation Instructions


Product Code: 0016-EVO-B

PAYMENT & DELIVERY INFORMATION

Please note all transactions are completed in GBP:

Paypal / Visa / Mastercard / AmexSecure Payment



DELIVERY – UK CUSTOMERS

Van icon

Goods will be shipped via courier within 1 working day of your order being placed (stock permitting). At the checkout stage you will be given Standard (£10 ex VAT) or Express (£20 ex VAT) shipping options. For more information visit our Delivery Information page.

DELIVERY – EUROPE & REST OF THE WORLD

Global delivery symbol

Goods will be shipped via Express courier service within 1 working day of your order being placed (stock permitting). For orders where the billing address is outside of the EU, 20% VAT will be deducted during the checkout stage. For expedited delivery please refer to our Dealer Locator page. For a full list of countries we ship to, plus service levels and prices, please visit our Delivery Information page.

T16 Evolution

16x high density 11W LEDs (premium ‘bin’)

Seamless, low profile design facilitates installation

Dynamic drive modulation optimises light output to preserve longevity of the LEDs

Ultra-reflective optics deliver ‘Drive’ beam pattern

CAE optimised heatsink

E-coat pre-treatment provides maximum corrosion resistance

Anodised aluminium heatsink provides for improved thermal dynamics (see Download section for Care Instructions)

5 Year Warranty

‘Unbreakable’ polycarbonate lens with lifetime guarantee*

IP67K rating

Comes as standard with 30cm cable, including pre-wired male & female connectors

Made in Britain

*Conditions apply

Technical Specifications
Voltage Range 9-32V
LED Life 50,000 hours
Weight 2142 gr
HIGH BEAM FUNCTION
Total Luminous Flux 16544 Lm
Colour Temperature 5000K
Number of High Output LEDs 16
Power Consumption 192 Watts
Current Draw (at 14.4V) 13.4 Amps
CERTIFICATION
High Beam Not certified
DIMENSIONS
Width 684 mm
Depth 68 mm
Height 64 mm
PHOTOMETRIC DATA
Horizontal Beam Angle 28 degrees
0.25 lx Line 1111 metres
0.5 lx Line 786 metres
1 lx Line 555 metres
3 lx Line 321 metres
