Toyota Land Cruiser (2024+) - Fog Light Upgrade Kit

Product Code
#BK-LC250-01

From €805.00

To €1,040.00

Fog Light Upgrade Kit   + €805.00
Toyota Land Cruiser (2024+) - Fog Light Upgrade Kit

In stock

€805.00

Find a
Stockist

Compatible with the Toyota Land Cruiser 250/Prado (2024+), Lazer’s Fog Light Upgrade Kit features a pair of Carbon-2 ‘DRIVE’ LED lights elevating the Land Cruiser’s lighting capabilities to deliver a dynamic, safer, more enjoyable night driving experience. Supplied pre-mounted into left-hand / right-hand lamp holders complete with bezels, on the one-hand the Carbon-2 lamps deliver a supplemental high beam driving light, and at the flick of a switch, a supplemental yellow dipped beam light output (for off-road use). The lamp holders themselves feature Lazer’s grain texture finish, which give the kits a rugged and tough appearance, without needing to be additionally painted.

With a combined 6,240 raw lumens (high beam mode), the Carbon-2 lights bring cutting edge motorsport tech to the road and off-road. Recent upgrades to the lamps allow for: a UNECE Reg 149 approved (Class B, E-Ref 12.5) driving light function for additional high beam performance, an ‘off-road’ dipped beam function (in yellow light) that helps cut through adverse weather conditions such as fog, dust, or rain. In addition, white and amber backlight functions are included with the lamps (the customer is able to set which colour they want to use, by programming the backlight function during installation).

The Lazer Fog Light Upgrade Kit replaces the original OE fog lights on the vehicle. Having removed the original lights, supplied cutting templates facilitate the fit and fitment of the lamps (supplied pre-mounted within their lamp holders), and once secured in place are finished with Lazer branded bezel. Within the upgrade kit we supply a twin-lamp wiring kit, while for vehicle’s with LED headlights, it will be necessary to utilise Lazer’s market-leading CANNY solution, mindful that the dipped beam function is a non-approved function for off-road use only and in certain markets this will need to be deactivated.

Like all Lazer products, the LC250 Fog Light Upgrade Kit, plus lights, are designed, engineered, and manufactured in the UK to the highest standards, and backed up by our comprehensive 5 year warranty.

PAYMENT INFORMATION

Please note all transactions are completed in Euros:
If you plan to reclaim VAT on any purchase and require a VAT receipt from your specific country, you will need to instead purchase through one of our local distributors.

Visa / Mastercard / AmexSecure Payment

DELIVERY – EU CUSTOMERS

Van icon

Goods will be shipped via courier within 2 working days of your order being placed (stock permitting), from Lazer Lamps’ warehouse in Belgium. At the checkout stage you will be given the option for Standard or Express shipping options. For more information visit our Delivery Information page. For lower cost, expedited deliveries, with country-specific VAT receipts, we would always encourage purchases to be made through one of our local distributors.

DELIVERY – EUROPE & REST OF THE WORLD

Global delivery symbol

Please visit www.lazerlamps.com for deliveries required outside of the EU.

Toyota Land Cruiser (2024+) - Fog Light Upgrade Kit

Fog Light Upgrade Kit for Toyota Land Cruiser 250/Prado (2024+) vehicles

Features Carbon-2 ‘Drive’ (with Yellow Dip Beam) LED driving lights

UNECE approved Reg 149 (Class B Driving Light, E-Ref 12.5) for on-road high beam function

Lamp housing and bezel made from UV-stable, high strength, PC-ABS material

Supplied cutting templates facilitate fitment

Includes twin-lamp wiring harness kits

Black and White lens covers available

5 year warranty

Designed and manufactured in the UK

Technical Specifications


2x Carbon-2 DRIVE
(Yellow Dip)


Voltage Range (DC) 10-32V
LED Life 50,000 hours
Weight 2x 192g

HIGH BEAM FUNCTION
Total Luminous Flux 6,240 Lm
Total Driver 'FOV' Flux † 3,672 Lm
High Beam Colour Temperature 5000K
Dip Beam Colour Yellow
Power Consumption 58 Watts
Peak Current Draw 5.2 Amps
Current Draw (14.4V) 4.2 Amps
Connector 4-Pin Deutsch DT (+15cm Cable)

CERTIFICATION
IP Rating # IP68
High Beam (E9 approval) ECE R149 - Ref: 2x 12.5
Backlight/PL Not Approved
EMC Certification ECE R10
Salt Spray Test ISO 9227
Dump Load Protection ISO 7637-2

PHOTOMETRIC DATA
Horizontal / Vertical Beam Angle 60° / 12°
0.25 lx Line 748m
0.5 lx Line 529m
1 lx Line 374m
3 lx Line 216m




† - Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45° left/right, and +/- 10° up/down. For more information – click here.

# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at our UK facility is fully submerged under water prior to sending out.

What's Included
  • Lamp Holder with 2x Carbon-2 DRIVE (Yellow Dip) pre-mounted (LH/RH)
  • Lamp Holder Bezel (LH/RH)
  • Positioning Templates (LH/RH)
  • Two-Lamp Wiring Kit
  • Black T-25 Torx Security Screws (x10) & Security Bit
  • VHB Cleaning Sachet (x2)

Fitting instructions available in the downloads section below.
