Ford Ranger Raptor (2023+) Grille Kit - Triple-R 16 Elite

Product Code
for Triple-R 16 Elite   + £834.00
Ford Ranger Raptor (2023+) Grille Kit - Triple-R 16 Elite

In stock


Find a

For an OE quality, auxiliary spotlight installation, the Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED Spotlights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles. Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure, with extra protection against theft.

The Ford Ranger Raptor, for vehicles produced since 2023+, includes a Triple-R 16 Elite High Performance LED driving light, plus wiring kit, alongside x2 brackets precision-engineered to engage perfectly with the standard centre grille on the vehicle, with added strength and security provided by the supplied self-tapping (plastic) screws. Made from high strength composite material, known for being exceptionally robust and UV stable. The brackets are fully weather and chemical resistant to ensure your installation remains in great condition year after year.

The Ford Ranger Raptor (2023+) Grille Integration Kit is carefully engineered and optimised for use with our Triple-R 16 Elite High Performance LED lightbar. Our warranty does not cover grille mounts which are fitted with non-Lazer Lamps’ branded products.



Please note all transactions are completed in GBP:

Paypal / Visa / Mastercard / AmexSecure Payment


Van icon

Goods will be shipped via courier within 1 working day of your order being placed (stock permitting). At the checkout stage you will be given Standard (£10 ex VAT) or Express (£20 ex VAT) shipping options. For more information visit our Delivery Information page.


Global delivery symbol

Goods will be shipped via Express courier service within 2 working days of your order being placed (stock permitting). Goods are typically sent DAP (Delivered At Place) meaning you will be liable for country specific VAT, import duties, and courier disbursement fees. For more information please visit our Payment Terms page. To avoid unnecessary charges, we would encourage customers to consider buying from a local dealer. For a full list of countries we ship to, plus service levels and prices, please visit our Delivery Information page.

Ford Ranger Raptor (2023+) Grille Kit - Triple-R 16 Elite

Bespoke vehicle integration kit for Lazer LED Spotlight installation

Custom fit for Ford Ranger Raptor (2023+)

Compatible with Triple-R 16 Elite LED Spotlight

Kit also includes bespoke mounting brackets and wiring kit with switch

Cutting guides included

Brackets made from high strength, UV -stable, composite material

5-year warranty

Made in Britain

Technical Specifications
  1x Triple-R 16 Elite
Voltage Range (DC) 10-32V
LED Life 50,000 hrs
Weight 3.2 kg
Total Luminous Flux

18040 Lm

Total Driver 'FOV' Flux † 11888 Lm
Colour Temperature 5000k
Number of High Output LEDs 16
Power Consumption 208 Watts
Current Draw (at 14.4V) 14.4 Amps
High Beam N/A
E-Mark Ref N/A
Horiz Beam Angle 30 Deg
0.25 lx Line 1920 metres
0.5 lx Line 1358 metres
1 lx Line 960 metres
3 lx Line 554 metres

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down. For more information – click here.

What's Included
  • 1x Grille Mounting Kit (includes cutting guides)
  • 1x Triple-R 16 Elite LED Lamp
  • 1x One-Lamp Wiring Kit
  • Installation Instructions
